Power Supply|MSI|750 Watts|Efficiency 80 PLUS BRONZE|PFC Active|MAGA750BNPCIE5
Couldn't load pickup availability
Cena bez PVN 21%: €66,36
Specifikācija
| Vienības kastes platums | 0.125 kg |
| Vienības kastes garums | 0.29 kg |
| Vienības kastes augstums | 0.21 kg |
| Modeļa nosaukums | MAG A750BN PCIE5 mm |
| Efektivitāte | 85 % |
| Units per Shipping Box | 6 mm |
| Unit Calculated Volume | 0.00943 cubm |
| Unit Calculated Weight | 2.45 kg |
| Summary | MSI MAG A750BN PCIE5. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Package width: 150 mm, Package depth: 140 mm, Package height: 86 mm kg |
| Combined power (+12V) | 750 W |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (+5Vsb) | 12.5 W |
| Combined power (-12V) | 3.6 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| Maximum input current (@220V) | 5 A |
| Total power | 750 W |
| Cabling type | Non-Modular W |
| EPS power connector (4+4 pin) | Jā W |
| Motherboard power connector | 24-pin ATX W |
| Number of SATA power connectors | 5 W |
| PCI Express power connectors (6+2 pin) | 2 W |
| 80 PLUS certification | 80 PLUS Bronze W |
| Power supply unit (PSU) form factor | ATX W |
| Fan diameter | 120 mm |
| On/off switch | Jā fan(s) |
| Power protection features | Over current/Over power/Over voltage/Short circuit A |
| Max output current (+12V) | 62.5 A |
| Maximum input current (@110V) | 10 A |
| Power Factor Correction (PFC) type | Active A |
| Floppy drive power connector | 1 W |
| PCI Express power connectors (16-pin) | 1 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Cooling type | Active W |
| Product colour | Black fan(s) |
| Peripheral (Molex) power connectors (4-pin) | 2 W |
| Purpose | PC W |
| Number of fans | 1 fan(s) |
| Package depth | 140 mm |
| Package height | 86 mm |
| Package width | 150 mm |
| ATX Power connector (24-pin) | Jā W |
| Illumination | Nē mm |
Apraksts
The MAG series fights alongside gamers in pursuit of honor. With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.
The MAG A750BN PCIE5's distinctive design patterns symbolize unity and strength. It unites all the components by reliably and stably supplying power to the entire system. With the MAG A750BN PCIE5's , any system has the power it needs to survive all challenges.
PCIE5.0 READY
It has an output port that is compliant with PCIe 5.0, enabling to support the RTX 4070* series graphics cards.
80 PLUS BRONZE CERTIFICATION
The efficiency of your power supply directly influences your system’s performance and power consumption. The 80 PLUS certification promises lower energy consumption and qualified efficiency level.
PROTECTION DEISGN
Protection is designed to protect the unit mechanisms and provides comprehensive protection.
TEMPERATURE ADAPTATION
Engineered for reliability, your system operates safely at peak performance even in high-temperature conditions. This rugged power supply ensures sustained operation regardless of your environment.
120MM LOW NOISE FAN
The 120mm fan reduces the noise generated while maintaining excellent heat dissipation.
