Power Supply|BE QUIET|Pure Power 13M|550 Watts|Peak Power 600 Watts|Efficiency 80 PLUS GOLD|BP024EU
Parastā cena
€109,11
Parastā cena
Akcijas cena
€109,11
Vienības cena
per
Nodoklis iekļauts.
Couldn't load pickup availability
Zīmols:
BE QUIET
Pieejamība:
Ir noliktavā
SKU:
BP024EU
Cena bez PVN 21%: €90,17
Parastā cena
€109,11
Parastā cena
Akcijas cena
€109,11
Specifikācija
| Vienības kastes platums | 0.2 kg |
| Vienības kastes garums | 0.29 kg |
| Vienības kastes augstums | 0.1 kg |
| Modeļa nosaukums | Pure Power 13M mm |
| Efektivitāte | 92.1 % |
| Units per Shipping Box | 6 mm |
| Unit Calculated Volume | 0.008211 cubm |
| Unit Calculated Weight | 2.92 kg |
| Summary | be quiet! Pure Power 13 M | 550W. Total power: 550 W, AC input voltage: 100 - 240 V, Peak power: 600 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500,650,800 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA kg |
| Units per Pallet | Pure Power 13M mm |
| Combined power (+12V) | 550 W |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Max output current (+12V1) | 45.8 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Maximum input current (@220V) | 5 A |
| Peak power | 600 W |
| Total power | 550 W |
| Cabling type | Fully-Modular W |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX mm |
| Number of SATA power connectors | 5 mm |
| PCI Express power connectors (6+2 pin) | 2 mm |
| Peripheral (Molex) power cable length | 800/950 mm |
| SATA power cable length | 500/650/800 mm |
| 80 PLUS certification | 80 PLUS Gold mm |
| ATX version | 3.1 mm |
| Power supply unit (PSU) form factor | ATX dB |
| Fan diameter | 120 mm |
| On/off switch | Jā fan(s) |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Surge & inrush protection (SIP)/Under voltage W |
| CPU power connector (4+4 pin) | Jā mm |
| Maximum input current (@110V) | 10 A |
| Power Factor Correction (PFC) type | Active W |
| Hold time | 21.68 ms |
| Power factor | 0.98 W |
| CPU power cable length | 650 mm |
| Bearing technology | Rifle mm |
| EPS version | 2.92 mm |
| Mean time between failures (MTBF) | 100000 h |
| Noise level | 20.8 dB |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Cooling type | Active dB |
| Product colour | Black fan(s) |
| Depth | 160 mm |
| Height | 86 mm |
| Width | 150 mm |
| Weight | 2230 g |
| Peripheral (Molex) power connectors (4-pin) | 2 mm |
| Purpose | PC dB |
| Number of fans | 1 fan(s) |
| CPU P4 connector (4-pin) | 2 W |
| Compliance certificates | BSMI/CB/CCC/CE/cTUVus/Federal Communications Commission (FCC)/IRAM/RCM/RoHS/TÜV mark/UKCA/WEEE °C |
| Package depth | 320 mm |
| Package height | 133 mm |
| Package weight | 3000 g |
| Package width | 210 mm |
| Cables included | AC,CPU,PCIe,Peripheral (Molex),SATA °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Sustainability certificates | ENERGY STAR/ErP mm |
| Products per shipping (inner) case | 6 pc(s) |
| Shipping (inner) case height | 233 mm |
| Shipping (inner) case length | 580 mm |
| Shipping (inner) case width | 325 mm |
| Fan speed | 0 - 1800 RPM |
| PCI Express power connectors (12-pin) | 1 mm |
| Cable ties included | Jā mm |
| Screws included | Jā mm |
| Number of +12V rail(s) | 1 A |
| Shipping (inner) case gross weight | 17900 g |
Apraksts
Exceptional quiet, superior features
Pure Power 13 M 550W is an ATX 3.1 compliant and PCIe 5.1 compatible power supply with semi-passive cooling. It offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 13 M 550W offers the best combination of features with outstanding compatibility.
- 80 PLUS® Gold efficiency (up to 93.8%)
- ATX 3.1 PSU with full support for PCIe 5.1 GPUs and GPUs with 6+2 pin connectors
- Handles massive power excursions
- Exceptionally silent semi-passive 120mm be quiet! fan
- Semi-passive construction for quiet and energy-saving operation
- LLC technology for advanced stability and voltage regulation
- One massive high-performance 12V-rail
- One PCIe 5.1 12V-2x6 300W and 2 PCIe 6+2 connectors for powerful GPUs
- Full suite of safety features
- Meets latest requirements for modern standby
