Power Supply|GIGABYTE|P450B|450 Watts|Efficiency 80 PLUS BRONZE|GP-P450B
Couldn't load pickup availability
Cena bez PVN 21%: €33,73
Specifikācija
| Vienības kastes platums | 0.21 kg |
| Vienības kastes garums | 0.255 kg |
| Vienības kastes augstums | 0.12 kg |
| Modeļa nosaukums | P450B mm |
| Efektivitāte | 85 % |
| Units per Shipping Box | 10 mm |
| Unit Calculated Volume | 0.008395 cubm |
| Unit Calculated Weight | 2.09 kg |
| Summary | GIGABYTE P450B. Total power: 450 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm kg |
| Combined power (+12V) | 432 W |
| Combined power (+3.3V) | 103 W |
| Combined power (+5V) | 103 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Max output current (+3.3V) | 18 A |
| Max output current (+5V) | 15 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Total power | 450 W |
| Cabling type | Non-Modular W |
| Floppy disk drive connector | Jā mm |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX mm |
| Number of SATA power connectors | 6 mm |
| PCI Express power connectors (6+2 pin) | 2 mm |
| Peripheral (Molex) power cable length | 500 mm |
| SATA power cable length | 500 mm |
| 80 PLUS certification | 80 PLUS Bronze mm |
| ATX version | 2.31 mm |
| Power supply unit (PSU) form factor | ATX h |
| Fan diameter | 120 mm |
| Fan location | Top mm |
| On/off switch | Jā fan(s) |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage A |
| CPU power connector (4+4 pin) | Jā mm |
| Max output current (+12V) | 36 A |
| Power Factor Correction (PFC) type | Active A |
| Floppy drive power connector | 1 mm |
| Hold time | 16 ms |
| Power factor | 0.9 A |
| ATX power connector (20+4 pin) | Jā W |
| CPU power cable length | 600 mm |
| PCI Express connector | Jā mm |
| PCI Express power cable length | 550 mm |
| Bearing technology | HDB mm |
| Mean time between failures (MTBF) | 100000 h |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Cooling type | Active h |
| Product colour | Black fan(s) |
| Depth | 140 mm |
| Height | 86 mm |
| Width | 150 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 mm |
| Purpose | PC h |
| Number of fans | 1 fan(s) |
| Input current | 8 - 4 A |
| Harmonized System (HS) code | 84733020 mm |
Apraksts
80 PLUS BRONZE CERTIFIED
80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
Reliable Flat Cable
P450B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.
120mm Silent Hydraulic Bearing (HYB) Fan
120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
- 80 PLUS Bronze certified
- 120mm Silent Hydraulic Bearing (HYB) Fan
- Reliable flat cable
- Single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
