Power Supply|XILENCE|650 Watts|Efficiency 80 PLUS GOLD|PFC Active|XN320
Parastā cena
€81,78
Parastā cena
Akcijas cena
€81,78
Vienības cena
per
Nodoklis iekļauts.
Couldn't load pickup availability
Zīmols:
XILENCE
Pieejamība:
Nav noliktavā
SKU:
XN320
Cena bez PVN 21%: €67,59
Parastā cena
€81,78
Parastā cena
Akcijas cena
€81,78
Specifikācija
| Vienības kastes platums | 0.1 kg |
| Vienības kastes garums | 0.265 kg |
| Vienības kastes augstums | 0.205 kg |
| Modeļa nosaukums | XN320 | XP650R12 mm |
| Units per Shipping Box | 1 mm |
| Unit Calculated Volume | 0.005432 cubm |
| Unit Calculated Weight | 2.17 kg |
| Summary | Xilence Gaming Gold Series XP650R12. Total power: 650 W, AC input voltage: 200 - 240 V, Peak power: 650 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, WEEE kg |
| Combined power (+12V) | 650 W |
| Combined power (+3.3V) | 100 W |
| Combined power (+5V) | 100 W |
| Max output current (+12V1) | 54.1 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Maximum input current (@220V) | 6.3 A |
| Peak power | 650 W |
| Total power | 650 W |
| Cabling type | Non-Modular W |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX mm |
| Number of SATA power connectors | 6 mm |
| PCI Express power connectors (6+2 pin) | 3 mm |
| 80 PLUS certification | 80 PLUS Gold mm |
| ATX version | 2.52 mm |
| Power supply unit (PSU) form factor | ATX mm |
| Fan diameter | 120 mm |
| On/off switch | Jā mm |
| Power protection features | Over current/Over power/Over voltage/Overheating/Short circuit/Under power W |
| CPU power connector (4+4 pin) | Jā W |
| Power Factor Correction (PFC) type | Active W |
| Bearing technology | Hypro Bearing mm |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 200 - 240 V |
| Cooling type | Active mm |
| Product colour | Black mm |
| Depth | 270 mm |
| Height | 95 mm |
| Width | 195 mm |
| Weight | 2300 g |
| Purpose | PC mm |
| Input current | 6.3 A |
| Compliance certificates | RoHS/WEEE mm |
| Sustainability compliance | Jā mm |
| Sustainability certificates | ErP mm |
Apraksts
The Gaming GOLD Series is a PC power supply series with a fixed cable harness, as well as a 750W ARGB variant. The noble design with its black powder coating, the 120mm silent, black or transparent fan and the fan grille emphasizes the valuable character of this series.
The maximum voltage stability and the six integrated safety circuits ensure safe operation even in heated workflows or gaming sessions. The power supplies are suitable for the highest demands in gaming, multi-media application and streaming areas and have low power consumption during these intensive phases. The power supplies achieve the 80+ GOLD requirements.
- Whisper-quiet cooling: Large 120mm fan*
- Excellent airflow design for improved heat dissipation
- With the following safety equipment:
- OVP (overvoltage protection)
- UVP (Undervoltage Protection)
- SCP (short circuit protection)
- OLP (overload protection)
- OTP (over temperature protection)
- OCP (overcurrent protection)
- Low standby power consumption
- High energy
