Mainboard|ASUS|Intel B760 Express|LGA1700|Micro-ATX|Memory DDR4|Memory slots 2|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|2xM.2|1x15pin D-sub|1xHDMI|2xUSB 2.0|4xUSB 3.2|1xPS/2|1xRJ45|3xAudio port|PRIMEB760M-KD4
Parastā cena
€109,34
Parastā cena
Akcijas cena
€109,34
Vienības cena
per
Nodoklis iekļauts.
Couldn't load pickup availability
Zīmols:
ASUS
Pieejamība:
Ir noliktavā
SKU:
PRIMEB760M-KD4
Cena bez PVN 21%: €90,36
Parastā cena
€109,34
Parastā cena
Akcijas cena
€109,34
Specifikācija
| Vienības kastes platums | 0.265 kg |
| Vienības kastes garums | 0.27 kg |
| Vienības kastes augstums | 0.055 kg |
| Modelis | PRIME B760M-K D4 g |
| Units per Shipping Box | 10 g |
| Unit Calculated Volume | 0.004834 cubm |
| Unit Calculated Weight | 0.998 kg |
| Summary | ASUS PRIME B760M-K D4. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. USB connector type: USB Type-A. Ethernet interface type: 2.5 Gigabit Ethernet kg |
| Compatible processor series | Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold channels |
| Processor manufacturer | Intel channels |
| Processor socket | LGA 1700 channels |
| Supported processor sockets | LGA 1700 channels |
| ECC ?ompatibility | Non-ECC channels |
| Maximum internal memory | 64 GB |
| Memory channels | Dual-channel GB |
| Memory slots type | DIMM GB |
| Number of memory slots | 2 GB |
| Supported memory clock speed (max) | 5333 MHz |
| Supported memory clock speeds | 2133/2400/2666/2800/2933/3000/3200/3333/3400/3466/3600/3733/4000/4266/4400/4600/4800/5000/5066/5333 MHz |
| Supported memory types | DDR4-SDRAM MHz |
| Unbuffered memory | Jā MHz |
| RAID levels | 0/1/10/5 MHz |
| RAID support | Jā MHz |
| Supported storage drive interfaces | M.2,SATA III MHz |
| Supported storage drive types | HDD & SSD MHz |
| Parallel processing technology support | Not supported MHz |
| 12V power connector | Jā MHz |
| ATX Power connector (24-pin) | Jā MHz |
| CPU fan connector | Jā MHz |
| EPS power connector (8-pin) | Jā MHz |
| Front panel audio connector | Jā MHz |
| Number of chassis fan connectors | 1 MHz |
| Number of COM connectors | 1 MHz |
| Number of SATA III connectors | 4 MHz |
| RGB LED pin header | Jā MHz |
| TPM connector | Jā MHz |
| USB 2.0 connectors | 2 MHz |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 MHz |
| Ethernet LAN (RJ-45) ports | 1 MHz |
| Microphone in | Jā MHz |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 MHz |
| Ethernet interface type | 2.5 Gigabit Ethernet MHz |
| Ethernet LAN | Jā MHz |
| Audio output channels | 7.1 channels |
| Component for | PC channels |
| Motherboard chipset | Intel B760 channels |
| Motherboard chipset family | Intel channels |
| Motherboard form factor | micro ATX channels |
| Number of M.2 (M) slots | 2 MHz |
| PCI Express x16 (Gen 4.x) slots | 1 MHz |
| BIOS memory size | 128 Mbit |
| BIOS type | UEFI AMI Mbit |
| PS/2 ports quantity | 1 MHz |
| Wake-on-LAN ready | Jā MHz |
| Number of HDDs supported | 4 MHz |
| Number of storage drives supported | 6 MHz |
| PCI Express x1 (Gen 4.x) slots | 2 MHz |
| HDMI ports quantity | 1 MHz |
| USB 2.0 ports quantity | 2 MHz |
| VGA (D-Sub) ports quantity | 1 MHz |
| Wi-Fi | Nē MHz |
| Depth | 211 mm |
| Width | 244 mm |
| Cables included | SATA mm |
| S/PDIF out connector | Jā MHz |
| Windows operating systems supported | Windows 10 x64/Windows 11 channels |
| Package depth | 51.5 mm |
| Package height | 263 mm |
| Package weight | 926.3 g |
| Package width | 270 mm |
| Height | 36 mm |
| Weight | 528 g |
| USB connector type | USB Type-A MHz |
