| Marketing Description | |
| Straight Power 12 is a future-proof ATX 3.0 power supply with 80 PLUS Platinum certification and virtually inaudible operation. | |
| Product Features | |
| |
| Product Properties | |
| Product Description | be quiet! Straight Power 12 - power supply - 850 Watt |
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 3.0/ EPS12V 2.92 |
| 80 PLUS Certification | 80 PLUS Platinum |
| Weight | 1.81 kg |
| Localisation | Europe |
| Input Voltage | AC 100-240 V |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 850 Watt |
| Output Current | +3.3V - 25 A +5V - 25 A +12V - 70.8 A -12V - 0.5 A +5VSB - 3 A |
| Output connectors | 1 x power 24 pin ATX with detachable 4 pin section 1 x power 8 pin +12V with detachable 4 pin section 1 x power 8 pin EPS12V 1 x 12VHPWR 4 x 8 pin PCI Express power with detachable 2 pin section 9 x 15 pin Serial ATA power 2 x Parallel ATA |
| Modular Cable Management | Yes |
| Cooling System | 135 mm fan |
| Included Accessories | Screws, cable ties |
| Colour | Black |
| Dimensions (WxDxH) | 15 cm x 16 cm x 8.6 cm |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 10 years warranty |
