NET CAMERA 5MP IR DOME/HDBW5541E-ZE-27135-S3 DAHUA
Regular price
€410,93
Regular price
Sale price
€410,93
Unit price
Tax included.
Couldn't load pickup availability
Brand:
DAHUA
Pieejamība:
Low stock
SKU:
IPC-HDBW5541E-ZE-27135-S3
Cena bez PVN 21%: €339,61
Regular price
€410,93
Regular price
Sale price
€410,93
Specifikācija
| Modelis | IPC-HDBW5541E-ZE-27135-S3 g |
| Units per Shipping Box | 1 g |
| Unit Calculated Volume | 0.007447 cubm |
| Unit Calculated Weight | 1.22 kg |
| Summary | Dahua Technology Pro IPC-HDBW5541E-ZE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Cube. Minimum illumination: 0.002 lx, Angle of rotation: 355°, Lens viewing angle, horizontal: 43°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"), Number of effective pixels (H x V): 2688 x 1520 pixels. Focal length range: 8 - 32 mm, Normal focusing range: 2.5 - 6 m kg |
| Connectivity technology | Wired kg |
| Adjustment shutter speed | Auto/Manual kg |
| Focal length range | 8 - 32 mm |
| Total megapixels | 4 MP |
| International Protection (IP) code | IP67 kg |
| Minimum illumination | 0.002 lx |
| Number of sensors | 1 pixels |
| LED type | IR m |
| Night vision | Jā m |
| Back Light Compensation (BLC) | Jā m |
| Highlight Compensation (HLC) | Jā fps |
| DC output voltage | 12 V |
| Placement supported | Indoor & outdoor kg |
| Mounting type | Ceiling/wall kg |
| Angle of rotation | 355 ° |
| Camera shutter type | Electronic s |
| Lens viewing angle, horizontal | 43 ° |
| Lens viewing angle, vertical | 23 ° |
| Pan range | 0 - 355 ° |
| White balance | Auto/Lamp/Manual/Natural/Outdoor ° |
| Number of effective pixels (H x V) | 2688 x 1520 pixels |
| Progressive scan | Jā " |
| Number of lenses | 1 m |
| Night vision distance | 80 m |
| Number of illumination LEDs | 3 m |
| Bit rate | H.264: 32 Kbps-8192 Kbps, H.265: 19 Kbps- 8192 Kbps m |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) m |
| Flip & mirror | Jā m |
| Frame rate | 30 fps |
| Gain control type | Auto/Manual fps |
| Noise reduction technology | 3D noise reduction pixels |
| Privacy masking | Jā pixels |
| Region of Interest (ROI) encoding | Jā pixels |
| Video streaming | Jā MP |
| Voice codecs | G.711a/G.711alaw/G.723/G.723.1/G.726/G.726-32 channels |
| Networking standards | IEEE 802.1x channels |
| Quality of Service (QoS) support | Jā user(s) |
| Streaming method | Multicast/Unicast user(s) |
| Supported network protocols | IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP ;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP ;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;SNMP user(s) |
| Card reader integrated | Jā user(s) |
| Video motion detection | Jā GB |
| Number of cameras | 1 g |
| Alarm input/output | Jā kg |
| Smart IR | Jā pixels |
| Audio input channels | 1.0 channels |
| Built-in HDD | Nē user(s) |
| Mirror | Jā GB |
| Management software | Smart PSS, DSS, DMSS GB |
| IK code | IK10 kg |
| Camera pan control | Jā ° |
| Camera tilt control | Jā s |
| Power consumption (Power over Ethernet (PoE)) | 12.4 W |
| Type | IP security camera kg |
| Form factor | Cube kg |
| Housing material | Metal kg |
| Product colour | White kg |
| Camera shutter speed | 1/3 - 1/100000 s |
| Tilt angle range | 0 - 65 ° |
| Optical sensor size | 1/1.8 " |
| Sensor type | CMOS " |
| Fixed focus | Jā " |
| Maximum resolution | 2688 x 1520 pixels |
| Noise reduction | Jā pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/2304 x 1296/2560 x 1440/2688 x 1520/352 x 240/352 x 288/640 x 480 (VGA)/704 x 576 pixels |
| Video compression formats | H.264/H.264+/H.265/H.265 Pro/H.265 Pro+/H.265+ MP |
| Bluetooth | Nē channels |
| Ethernet interface type | Fast Ethernet channels |
| Ethernet LAN | Jā channels |
| Number of users | 20 user(s) |
| Wi-Fi | Nē user(s) |
| Compatible memory cards | MicroSD (TransFlash) user(s) |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 GB |
| Web browser | Jā GB |
| Power source type | AC,DC,PoE W |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Depth | 159 mm |
| Height | 117.9 mm |
| Weight | 950 g |
| Auto focus | Jā " |
| Maximum aperture number | 1.6 mm |
| Digital Wide Dynamic Range (DWDR) | Jā m |
| Audio formats supported | AAC MP |
| DC-in jack | Jā GB |
| Motion sensor | Jā GB |
| Privacy protection | Jā GB |
| Web-based management | Jā GB |
| Mobile operating systems supported | Android/iOS °C |
| Fog proof | Jā kg |
| Audio output channels | 1.0 channels |
| People counting function | Jā kg |
| Supported video modes | 1080p/720p pixels |
| Active tampering alarm | Jā GB |
| Video intelligence analytic | Jā MP |
| Manual | Jā g |
| Plug and Play | Jā kg |
| Auto flip | Jā ° |
| Normal focusing range | 2.5 - 6 m |
| AC input voltage | 24 V |
| Windows operating systems supported | Jā °C |
Apraksts
- 1/2.7” 5Megapixel progressive scan CMOS
- H.265 & H.264 triple-stream encoding
- 20 fps@2592 × 1944, 50/60 fps@1080P (1920 × 1080)
- WDR (120 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
- Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
- 2.7 mm–13.5 mm motorized lens
- 1/1 Alarm in/out, 1/1 audio in/out
- Max. IR LEDs Length 40 m
- Micro SD memory, IP67, IK10
