Mainboard|GIGABYTE|Intel Z890|LGA1851|ATX|Memory DDR5|Memory slots 4|Z890AELITEWIFI71.0
Regular price
€273,50
Regular price
Sale price
€273,50
Unit price
per
Tax included.
Couldn't load pickup availability
Brand:
GIGABYTE
Pieejamība:
Out of stock
SKU:
Z890 A ELITE WIFI7 1.0
Cena bez PVN 21%: €226,03
Regular price
€273,50
Regular price
Sale price
€273,50
Specifikācija
| Vienības kastes platums | 0.27 kg |
| Vienības kastes garums | 0.34 kg |
| Vienības kastes augstums | 0.08 kg |
| Modelis | Z890 A ELITE WIFI7 g |
| Bluetooth | Jā MHz |
| Bluetooth versija | 5.4 MHz |
| Units per Shipping Box | 6 g |
| Unit Calculated Volume | 0.0101 cubm |
| Unit Calculated Weight | 2.52 kg |
| Summary | GIGABYTE Z890 AORUS ELITE WIFI7 Motherboard - Supports Intel Core Ultra (Series 2) CPUs, 16+1+2 phases VRM, up to 8800MHz DDR5 (OC), 1xPCIe 5.0 + 3xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel kg |
| Compatible processor series | Intel Core Ultra (Series 2) channels |
| Processor manufacturer | Intel GB |
| Processor socket | LGA 1851 (Socket V1) GB |
| Supported processor sockets | LGA 1851 GB |
| ECC ?ompatibility | Non-ECC GB |
| Maximum internal memory | 256 GB |
| Memory channels | Dual-channel GB |
| Memory slots type | DIMM GB |
| Number of memory slots | 4 GB |
| Supported memory clock speed (max) | 8800 MHz |
| Supported memory clock speeds | 5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600/7800/7900/7950/8000/8200/8266/8400/8600/8800 MHz |
| Supported memory types | DDR5-SDRAM MHz |
| RAID levels | 0/1/10/5 MHz |
| RAID support | Jā MHz |
| Supported storage drive interfaces | M.2,SATA III MHz |
| Supported storage drive types | HDD & SSD MHz |
| On-board graphics card | Nē MHz |
| 12V power connector | Jā MHz |
| ATX Power connector (24-pin) | Jā MHz |
| EPS power connector (8-pin) | Jā MHz |
| Number of SATA III connectors | 4 MHz |
| RGB LED pin header | Jā MHz |
| TPM connector | Jā MHz |
| USB 2.0 connectors | 2 MHz |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 MHz |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 MHz |
| Ethernet LAN (RJ-45) ports | 1 MHz |
| Microphone in | Jā MHz |
| Thunderbolt ports quantity | 1 MHz |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 MHz |
| Ethernet interface type | 2.5 Gigabit Ethernet MHz |
| Ethernet LAN | Jā MHz |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) MHz |
| Wi-Fi standards | Wi-Fi 7 (802.11be) MHz |
| Audio chip | Realtek ALC1220 kg |
| Audio output channels | 7.1 channels |
| Component for | PC channels |
| Motherboard chipset | Intel Z890 channels |
| Motherboard chipset family | Intel channels |
| Motherboard form factor | ATX channels |
| Number of M.2 (M) slots | 4 MHz |
| PCI Express x16 (Gen 4.x) slots | 2 MHz |
| PCI Express x16 (Gen 5.x) slots | 1 MHz |
| BIOS memory size | 256 Mbit |
| S/PDIF out port | Jā MHz |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 MHz |
| BIOS type | UEFI AMI Mbit |
| Clear CMOS button | Jā Mbit |
| DirectX version | 12.0 MHz |
| PC health monitoring | Fan/Temperature/Voltage channels |
| ACPI version | 5.0 MHz |
| System Management BIOS (SMBIOS) version | 2.7 Mbit |
| Bundled software | Norton® Internet Security (OEM version) LAN bandwidth management software mm |
| Number of HDDs supported | 8 MHz |
| Number of storage drives supported | 4 MHz |
| Clear CMOS jumper | Jā Mbit |
| HDMI ports quantity | 1 MHz |
| USB 2.0 ports quantity | 4 MHz |
| Wi-Fi | Jā MHz |
| Depth | 244 mm |
| Width | 305 mm |
| Maximum internal memory supported by processor | 256 GB |
| Supported memory module capacities | 12GB/16GB/1GB/24GB/2GB/32GB/40GB/48GB/4GB/64GB/8GB MHz |
| Total number of SATA connectors | 4 MHz |
| DisplayPorts quantity | 2 MHz |
| Product colour | Black channels |
| Windows operating systems supported | Windows 11 x64 channels |
| Desktop Management Interface (DMI) version | 2.7 Mbit |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) Mbit |
| Battery type | CR2032 Mbit |
| Battery weight | 3 g |
| Country of origin | China g |
| Lithium weight per battery | 0.07 g |
| Number of battery cells | 1 g |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 2500 g |
| Package width | 335 mm |
| Products per shipping (inner) case | 1 pc(s) |
| Height | 35 mm |
| Batteries included | Jā mm |
| Warranty period | 3 year(s) |
| Weight | 2230 g |
| Number of EPS power connectors (8-pin) | 1 MHz |
| WLAN controller model | MediaTek MT7925 MHz |
Apraksts
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
- Digital 16+1+2+1 Phases 80A SPS VRM with Tantalum Polymer Capacitor
- Reinforced PCIe UD Slot X PCIe 5.0 with PCIe EZ-Latch Plus Design
- PCIe M.2 design (Up to 25110) with M.2 EZ-Latch Plus & Thermal Guard
- Fully Covered MOSFET Heatsinks with heatpipe/M.2 EZ-Latch Click Design
- 2x2 Wi-Fi 7 with WIFI EZ-Plug Design
- 2.5GbE LAN, THUNDERBOLT 4 Type-C, USB 3.2 Gen2 Type-C
