Power Supply|SEASONIC|ATX|PC|100 - 240 V|750 W|SRP-CBC751-A5A51JF
Couldn't load pickup availability
Cena bez PVN 21%: €57,48
Specifikācija
| Vienības kastes platums | 0.24 kg |
| Vienības kastes garums | 0.114 kg |
| Vienības kastes augstums | 0.185 kg |
| Units per Shipping Box | 5 mm |
| Unit Calculated Volume | 0.00648 cubm |
| Unit Calculated Weight | 2.43 kg |
| Summary | Seasonic CORE BC-750 ATX 3.1. Total power: 750 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, CPU power cable length: 60 cm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: BSMI, CB, CCC, CE, EAC, REACH, RoHS, UKCA, WEEE, cTUVus, Certification: CE, CB, CCC, cTUVus, TUV, BSMI, EAC, UKCA, Energy Star, RoHS, REACH, WEEE, ErP Lot 6 kg |
| Units per Pallet | ENERGY STAR mm |
| Combined power (+12V) | 744 W |
| Combined power (+3.3V) | 100 W |
| Combined power (+5Vsb) | 12.5 W |
| Combined power (-12V) | 3.6 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| Total power | 750 W |
| Cabling type | Non-Modular W |
| EPS power connector (4+4 pin) | Jā mm |
| Motherboard power cable length | 550 mm |
| Motherboard power connector | 20+4 pin ATX mm |
| Number of SATA power connectors | 6 mm |
| PCI Express power connectors (6+2 pin) | 4 mm |
| 80 PLUS certification | 80 PLUS Bronze mm |
| Power supply unit (PSU) form factor | ATX h |
| Fan diameter | 120 mm |
| Fan location | Top mm |
| On/off switch | Jā fan(s) |
| Power protection features | Over current/Over power/Over voltage/Short circuit A |
| CPU power connector (4+4 pin) | Jā mm |
| Max output current (+12V) | 62 A |
| ATX power connector (20+4 pin) | Jā W |
| CPU power cable length | 600 mm |
| PCI Express connector | Jā mm |
| Bearing technology | Sleeve mm |
| Mean time between failures (MTBF) | 100000 h |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Cooling type | Active h |
| Product colour | Black fan(s) |
| Depth | 140 mm |
| Height | 86 mm |
| Width | 150 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 mm |
| Purpose | PC h |
| Number of fans | 1 fan(s) |
| Input current | 11 - 5.5 A |
| Compliance certificates | BSMI/CB/CCC/CE/cTUVus/EAC/REACH/RoHS/UKCA/WEEE °C |
| Certification | CE, CB, CCC, cTUVus, TUV, BSMI, EAC, UKCA, Energy Star, RoHS, REACH, WEEE, ErP Lot 6 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Sustainability certificates | ENERGY STAR mm |
Apraksts
CORE BC – Power Made Simple
The Seasonic CORE BC Series delivers reliable performance and modern ATX 3.1 compliance at an essential value. Designed for everyday builders and gamers, it embodies Seasonic’s trusted quality in a compact 140 mm design with a durable scratch-resistant finish.
With 80 PLUS® Bronze efficiency, Smart and Silent Fan Control (S2FC), and a 120 mm HDB fan, it ensures cool, quiet, and stable operation. The CORE BC-750 and CORE BC-850 include a 12V-2×6 PCIe Gen 5.1 cable, ready for the latest GPUs, while the CORE BC-650 meets all ATX 3.1 requirements with traditional connectors.
Built on decades of engineering excellence, the CORE BC Series delivers the quiet efficiency, reliability, and durability that define every Seasonic power supply.
Next-Gen and Legacy GPU Cable
Includes native 12V-2x6 and 2× 8-pin cables for maximum compatibility
S2FC - Intelligent Fan Control Technology
The Smart and Silent Fan Control (S2FC) system intelligently regulates the power supply’s fan speed to achieve the ideal balance between cooling efficiency and silent operation. By dynamically adjusting the fan curve according to temperature, it ensures that your system remains quiet during low-to-medium usage and effectively cooled when performance demands increase.
