Power Supply|CHIEFTEC|700 Watts|Efficiency 80 PLUS|PFC Active|ZPU-700S
Regular price
€50,63
Regular price
Sale price
€50,63
Unit price
per
Tax included.
Couldn't load pickup availability
Brand:
CHIEFTEC
Cena bez PVN 21%: €41,84
Regular price
€50,63
Regular price
Sale price
€50,63
Specifikācija
| Vienības kastes platums | 0.1 kg |
| Vienības kastes garums | 0.255 kg |
| Vienības kastes augstums | 0.18 kg |
| Modeļa nosaukums | ZPU-700S year(s) |
| Units per Shipping Box | 1 year(s) |
| Unit Calculated Volume | 0.00459 cubm |
| Unit Calculated Weight | 1.71 kg |
| Summary | Chieftec EON . Total power: 700 W, AC input voltage: 200 - 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 450,600,750 mm. Purpose: PC/Server, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm kg |
| Combined power (-12V) | 4.8 W |
| Max output current (+12V1) | 53 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.4 A |
| Maximum input current (@220V) | 5.5 A |
| Total power | 700 W |
| Cabling type | Non-Modular W |
| EPS power connector (4+4 pin) | Jā W |
| Motherboard power cable length | 650 mm |
| Motherboard power connector | 20+4 pin ATX mm |
| Number of SATA power connectors | 4 mm |
| PCI Express power connectors (6+2 pin) | 2 mm |
| Peripheral (Molex) power cable length | 450/600/750 mm |
| SATA power cable length | 450/600/750 mm |
| 80 PLUS certification | 80 PLUS mm |
| ATX version | 2.3 mm |
| Power supply unit (PSU) form factor | ATX mm |
| Fan diameter | 120 mm |
| On/off switch | Jā mm |
| Power protection features | Short circuit/Surge and inrush/Surge protection A |
| CPU power connector (4+4 pin) | Jā W |
| Power Factor Correction (PFC) type | Active A |
| Power factor | 0.9 A |
| ATX power connector (20+4 pin) | Jā W |
| AC input frequency | 50 Hz |
| AC input voltage | 200 - 240 V |
| Product colour | Black mm |
| Depth | 140 mm |
| Height | 86 mm |
| Width | 150 mm |
| Weight | 1400 g |
| Purpose | PC/Server mm |
| Input current | 5.5 A |
| Supported motherboard form factors | ATX mm |
| Warranty period | 2 year(s) |
Apraksts
The EON Series offers high quality and 80 PLUS® 230V EU efficiency at highly
competitive pricing, equipped with silent 120mm fans.
The power supplies are fully built from steel, coated in elegant black, and
equipped with extra-long native cables. The EON Series runs quietly and provides
its power with all essential protection and safety features.
